Orbit Control Star 9 station outdoor controller

Control Star 9 Station slide controller

$347.10 per ea
Sold Out

No other timer gives you so much information at a glance. Rather than going through the hassle of pressing many different buttons and going through dozens of displays, adjust the duration of a station by simply sliding the switch.

Calculate Shipping

No other timer gives you so much information at a glance. Rather than going through the hassle of pressing many different buttons and going through dozens of displays, adjust the duration of a station by simply sliding the switch. Programming has never been easier or faster.


Features and Benefits

  • Heavy-Duty Cabinet - Tough, impact, water and UV resistant material helps your timer withstand the test of time
  • Keyed Lock - Added security and prohibits tampering

(046878573888)

Features and Benefits

  • Three independant programs A, B and C
  • Station timing in one minute increments for precision time requirements using rotary dial 1 minute to 120 minutes
  • Station timing using slide switches 2 minutes to 120 minutes
  • Four start times per program
  • 7-Day calendar specifies watering by day of week
  • Program Odd, Even and Interval (1 to 32 days) day watering on A, B or C programs
  • Program “No Watering” by specific day of week, or by daily time period
  • Master valve/Pump start programmable by individual station
  • 0 minutes to 9 hour programmable delay between stations
  • Semi automatic programmable rain delay from 24-72hours, 4-99 days
  • Seven operation modes: Auto, Manual, Extra, Test, Rain Delay, Water Budgeting, Off

Electrical Specifications:

  • Input required: 240vac +/- 10%, 50 Hz
  • 24vac at 0.6 amps
  • Valve Capacity: one valve plus pump start

Mechanical Specifications:

  • OUTDOOR Lock Mechanism: Keyed latch, two keys provided
  • Valve Wiring Access Hole: 33mm diameter with glueless rubber grommet
  • Primary Power Access: 15mm threaded conduit adapter

Dimensions:

  • Height: 16.5 cm
  • Width: 23.5 cm
  • Depth: 5.2 cm
  • Inlet Size: 3.2 cm



SKU 046878573888
Brand Orbit
Shipping Weight 1.8990kg
Shipping Width 0.255m
Shipping Height 0.205m
Shipping Length 0.120m
Shipping Cubic 0.006273000m3
Unit Of Measure ea
